Cable Gland Liquid Tight Black

Product Code: 3234
Manufacturer: Heyco
UOM: EACH
3/4" NPT threaded cable glands for securing cables through threaded holes. Rated IP 68. Fit cables from 11.4mm to 18mm in diameter.
Products specifications
DescriptionCable Gland
TypeLiquid Tight
ColourBlack
MaterialNylon 66
Length16mm
Width33mm
Internal Hole Diameter27.1mm
Thread Length16mm
Thread PitchNPT ¾"
Cable Size Minimum11.4mm
Cable Size Maximum18mm
IP RatingIP 68
Minimum Temperature-40°C
Maximum Temperature115°C
Flammability Rating94V-2
CertificationsUL, CSA
Other informationIncludes Nylon Nut
