Cable Gland Liquid Tight Black

Product Code: 8437
Manufacturer: Heyco
UOM: EACH
1" NPT threaded cable glands for securing cables through threaded holes. Rated IP 68. Fit cables from 15mm - 25.4mm in diameter.
Products specifications
DescriptionCable Gland
TypeLiquid Tight
ColourBlack
MaterialNylon 66
Length61.5mm
Width41.9mm
Internal Hole Diameter34.3mm
Thread Length19.1mm
Thread PitchNPT 1"
Cable Size Minimum15mm
Cable Size Maximum25.4mm
IP RatingIP 68
Minimum Temperature-40°C
Maximum Temperature115°C
Flammability Rating94V-2
CertificationsUL, CSA
