Strain Relief Bushing Straight-Thru - For Flat Cables Black

Name: Strain Relief Bushing Straight-Thru - For Flat Cables Black
SKU: 1484
Availability: InStock

Product Code: 1484

Manufacturer: Heyco

UOM: EACH

Black strain relief bushings for flat cables. Fit SPT-2 cables measuring AWG 18/3 (3.8mm x 10.2mm), 16/3 (4.1mm x 10.4)) & SPT-3 cables measuring AWG 18/2 (4.8mm x 8.9mm), 18/3 (4.8mm x 9.9mm), 16/2 (5.1mm x 9.4mm) or 16/3 (5.1mm x 10.9mm).

Download Datasheet

Products specifications

Description	Strain Relief Bushing
Type	Straight-Thru - For Flat Cables
Colour	Black
Material	Nylon 66
Length	21.8mm
Mounting Hole Diameter	14.3mm
Panel Thickness	3.2mm
Cable Size AWG	18 - 16
Cable Size Minimum	3.8 x 10.2mm
Cable Size Maximum	5.1 x 9.4mm
Minimum Temperature	-18°C
Maximum Temperature	105°C
Flammability Rating	94V-2
