    Picture of Terminal Block Screw to Tab White

    Terminal Block Screw to Tab White

    Product Code: 9451
    Manufacturer: Heyco
    UOM: EACH
    Flame resistant terminal blocks with 3 poles. Rated 450V 40A (AEC) or 600V 40A (American). Fit AWG 18-8 (10mm²) wires.
    Download Datasheet
    Login to purchase this item
    Products specifications
    DescriptionTerminal Block
    TypeScrew to Tab
    ColourWhite
    MaterialNylon and Galvanised Steel
    Length81mm
    Width15mm
    Height25.4mm
    Screw SizeM5
    Number of Poles3
    Voltage Rating600V
    Current Rating40A
    Cable Size mm10mm²
    Cable Size AWG18 - 8
    Minimum Temperature-18°C
    Maximum Temperature150°C
    Flammability Rating94V-0
    CertificationsUL
